| Picture | Model | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Classic 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/180 | G1 1/2 |
 |
Classic E 25-6 | 25 | 2 | 3 | 6 | 230 | 50/60 | 45 | 130/180 | G1 1/2 |
 |
Classic S 20-5 | 20 | 1.5 | 2.7 | 5 | 230 | 50/60 | 32 | 130 | G1 |
 |
Basic 32-12S Pro | 32 | 6 | 8 | 12 | 230 | 50 | 500 | 180/220 | G2- G1 1/2 or G2- G1 1/4 |
 |
Basic 32-12SF Pro | 32 | 6 | 8 | 12 | 230 | 50 | 500 | 220 | DN32 – G2 |
 |
Basic 32-9SF Pro | 32 | 5 | 6.5 | 9 | 230 | 50 | 300 | 220 | DN32 – G2 |
|
Basic 32-9S Pro | 32 | 5 | 6.5 | 9 | 230 | 50 | 300 | 180/220 | G2- G1 1/2 or G2- G1 1/4 |
|
Basic 25-12S Pro | 25 | 3.5 | 9 | 12 | 230 | 50 | 300 | 200 | G1 1/2-G1 |
